Shore D Basic

DESCRIPTION:

ADIS Durometers Shore D (Basic) is made from a special Zinc alloy, which allows our durometers to be compact in size, without compromising their durability and strength.

The key benefit of our Durometer is the unique design of its transmission system, which allows us to use HSS (High-Speed Steel) Rods as Indenter (Contact point) which is then guided on Linear Ball Bearings and not on Bush Bearings like in most Durometers, as a result, the coefficient of friction is significantly lower while using the Durometer. Hence, results in smoother transmission and increases our Durometers sensitivity.

It’s designed to fit comfortably & firmly in your hand.

It has an Accuracy of ± 2 HA (Used by finished products or components with low tolerance & for educational purposes)

Measuring force of 44.49 N (4.540 gm.)

Indenter (contact point) is made of HSS Rod and has a hardness of 60 HRC which is ground to the shape of a cone with the included angle of 30° with close tolerances of ± 0°30” and nose radius of 0.1 mm.

Its pressure foot diameter is 18 mm. (± 0.5mm.)

Its net weight is approximately 250 grams.

Its Dimensions are (L x W x H) 58 x 33 x 95 mm.

It is used to measure the hardness of Polyester (Plastics), ABS, Hard Nylon, Hard PU, Kevlar, Acrylic, Wood, Vulcanised Rubber, Ebonite, Etc.

It is made in INDIA.

SPECIFICATION:-

Standards	ASTM D 2240 / DIN 53505
Indication range	0 - 100 Div. (360° dial scale)
Minimum indication	1 Shore
Accuracy	± 2 Shore
Indenter Design	Conical 30° Included Angle
Spring Forces (N)	44.49 N
Indenter Image
Pressure foot Dimension	Ø 18 mm.
Approx. Outer Dimension (mm)	(L×W×H)   62 x 33× 95
Weight (g)	180 g
Application	To determine indentation hardness of Pipeline Coating, Hard Rubber, Acrylic, Delrin, Kevlar, PVC, Nylon, Lexan, and Epoxies.
